SecurityMan ClearCam II - Manual (Page 18)

19
Specification
CAMER
A(SM
-8123T
)
RECEIVER(SM
-7034)
Imaging Senor CMOS
Total Pixels 510 x 492(NTSC)
Minimum illumination OLux
Transmission Frequency ISM 906MHz & 924MHz (CH2, Manual/Loop)
Transmission Power 10mW/CE: 2mW/FCC
Modulation Type FM
Bandwidth 18MHz
Power Supply ±12VDC
Consumption Current 90mA(IR OFF) & 260mA(IR ON)
Unobstructed Effective Range 100m
Night Vision Range
15m(45ft)
Dimension(WxDxH) 61x96x136(mm)(Including Bracket)
Weight 296g
Receiving Frequency ISM 900MHz ~ 930MHz
Intermediate Frequency 480MHz
Demodulation Type FM
Antenna 50ohmSMA
Receiving Sensitivity ≤-85dBm
Video Output Level 1.1V+/–0.2V
pp
@75 ohm,S/N>38dB
Audio Output Level 3.0V+/–1V
pp
@600 ohm
Power Supply +8VDC
Consumption Current 165mA
Dimension(WxDxH) 78x92x22(mm)(Excluding Antenna)
Weight 174g
Operating Temperature -10˚C~50˚C/±14˚F~+122˚F
Operating Humidity 85%RH
Item Value
