Installation Diagram
WARNING: When using power adapter, make sure the voltage indica-
tions on the adapters are compatible to the devices to avoid potential
damages for incorrect usage of power.
Installation
A) Setting up the Antennas
Connect the antennas to the receiver and camera
CH2
CH1
SET
A / V Cable
VCR/DVR
Or
AC
adapter
CH4
CH
2
CH1
SET
