7
ACR2005 Refrigerant Service Solution
ACR2005
Temperature and Velocity Probes
(located on back panel)
COMPONENT LOCATION AND IDENTIFICATION
Blue
Temp
Probe
Red
Temp
Probe
RS232 Outlet
Oil Drain Bottle
simply snaps
into place.
(Verify the
drain tube is
inside the bottle.)
A/C System
Close-Up of Oil Drain Connection
(located on side panel near tank)
Circuit
Breakers
INST0687
INST0688
Anemometer
Introduction
TEMP PROBE
CONTROL BREAKER
MAIN POWER BREAKER
TEMP PROBE
AIR FLOW
RS232
RED
BLUE
