Check for parts online at www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5 16
Operator's Manual
Rivers Edge Two-Man Ladder Stands
lADDER PARTS lIST
kEY # PART # DESCRIPTION QTY.
1 48240B BOLT, HHCS GR5 BLK 1/4-20 X 1-1/2" 4
2 48153B BOLT, HH GR5 BLK 1/4-20 X 2" 4
3 48261B WASHER, BLK 1/4" 24
4 48270B BOLT, HH GR5 BLK 1/4-20 X 2-1/2" 6
5 48271B BOLT, HHCS, GR5 BLK 1/4-20 X 2-1/4" 18
6 48752B NUT, FLANGED, NYLOCK 1/4-20 32
7 48679 RUBBER BUMPER STOP 4
8 63281 SPRING LOCK PIN, ROUNDED
RETAINER 1/4 X 1-3/4"
8
9 1ML23 SUPPORT TUBE, STABILIZER 1
10 2ML46 SUPPORT TUBE 2
11 2ML64 SHOOTING RAIL 1
12 2ML65 BACKREST RAIL 1
13 2ML69 FLIP UP SEAT PLATFORM 1
14 2ML93 SEAT SUPPORT LOOPS 2
15 2ML127 TREE BLADE FRAME 1
16 2ML129 SIDE RAIL, FOOT PLATFORM SUPPORT 2
17 2ML130 TREE BLADE 1
18 2ML133 FOOT PLATFORM 2
19 L17 STABILIZER BAR 1
20 LL9A SUPPORT BRACE, PLATFORM 2
21 SL51 4-STEP LADDER, POCKET/PIN STYLE 1
22 SL52 4-STEP LADDER W/VAM,
POCKET/PIN STYLE
1
23 SL54 4-STEP LADDER W/HOLES,
POCKET/PIN STYLE
1
24 WN516 WASHER, NYLON BLK 5/16" 4
25 48688 BENCH SEAT CUSHION, 2" W/BACKREST 1
26 48739 CAMO SLEEVE, 36" 1
27 48736 CAMO SLEEVE, 9" 2
ITEMS BElOW NOT SHOWN
-- 48415 RATCHET STRAP 2
-- 48155 FULL BODY HARNESS (FAS) 2
-- 48691 ROPE, 9' (SOLD IN ROPE KIT ONLY) 1
-- 48691 TIE-OFF ROPE, 15' (SOLD IN ROPE KIT ONLY) 2
NO EXTENSIONS AvAIlABlE FOR THIS MODEl,
TESTED FOR 17' MAXIMuM HEIGHT!
