Dr-1 fluid regulator - maintenance – Ransburg DR-1 Fluid Regulator 74151 User Manual
Page 18
DR-1 Fluid Regulator - Maintenance
15
General Problem
Cause
Solution
Inconsistent Fluid
Flow
High Fluid Flow
1. Item 8 (lower diaphragm)
stretched from excessive
air pilot signal
2. Ruptured Item 9 (upper
diaphragm)
3. Ruptured Item 14 (center
diaphragm)
4. Inconsistent air pilot
5. Inconsistent fluid supply
pressure
1. Incorrect regulator ratio
2. Fluid supply pressure too
high
1. Rebuild regulator.
2. Rebuild regulator.
3. Rebuild regulator.
4. Check pilot air supply.
5. Check fluid supply.
1. Refer to "Operations" section for correct
sizing information.
2. Lower fluid supply pressure.
LN-9223-00.10
