Ransburg Serial Atomizer Module A11925-00 User Manual
Page 13

LN-9256-07.4
Serial Atomizer Module - Operation
1 0
1 0
1 0
1 0
1 0
7. Can be used in conjunction with a Serial
Node Adapter communicating on same bus:
Serial Atomizer takes its speed command from
the Serial Speed Select Module only when its
"Bell Enable" switch (that bell only) is in the
"Enabled" position. Otherwise, Serial Atomizer
receives command from the Serial Node Adapter.
This feature requires Serial Node Adapter software
Version 2.21 (EPROM 77128-07) and Serial Speed
Select software Version 0.3 (EPROM 79130).
When using multiple Serial Atomizer Modules, the
Node Adapter must be set to Flex Mode
communication (see Figure 5 for switch settings).
8. With the "Atomizer Select" knob in the "0" (fully
counter-clockwise) position, all Serial Atomizer
Modules will display their status number.
9. Once a speed has been entered, a Serial Ato-
mizer will run at that speed until the "Enable"
switch is set to OFF. If the Enable is set back
to ON, the bell will run at the previously entered
speed, without an entry by the Speed Enter"
button. If a Serial Node Adapter is used, remember
that it will supply the speed command when the
"Enable" switch is in the OFF position.
10.The "zero" position of the rotary switch will
instruct the Serial Atomizer to display fault status.
(See Figure 5 for the error codes.)
Figure 1: 79128-00 Serial Atomizer Speed Select
Figure 1: 79128-00 Serial Atomizer Speed Select
Figure 1: 79128-00 Serial Atomizer Speed Select
Figure 1: 79128-00 Serial Atomizer Speed Select
Figure 1: 79128-00 Serial Atomizer Speed Select
79128-00 SERIAL
79128-00 SERIAL
79128-00 SERIAL
79128-00 SERIAL
79128-00 SERIAL
A
A
A
A
AT
T
T
T
TOMIZER SPEED
OMIZER SPEED
OMIZER SPEED
OMIZER SPEED
OMIZER SPEED
SELECT
SELECT
SELECT
SELECT
SELECT OPERA
OPERA
OPERA
OPERA
OPERATIONAL
TIONAL
TIONAL
TIONAL
TIONAL
PROCEDURE
PROCEDURE
PROCEDURE
PROCEDURE
PROCEDURE
1. Must be used with Serial Atomizer Module only.
2. Must be used in Quarter Rack Motherboards
(78145 or 78147).
3. No motherboard wiring is required.
4. Can run 1-4 Serial Atomizer Modules as stand-
alone system.
5. The bell number 1 refers to the Serial Atomizer
with the lowest serial rack address, bell number 2
to the next highest, etc.
6. To command a speed, set the "Enable" switch
for the desired bell to ON, set the "Atomizer
Select" knob to that number, enter a number in
krpm using the thumbwheels, and then press
the "Speed Enter" button.
