Serial Atomizer Module - Installation
8
8
8
8
8
INSTALLATION
LOCA
LOCA
LOCA
LOCA
LOCATION
TION
TION
TION
TION
Install the rack assembly in a control cabinet that
is protected from the possibility of any contact with
water, vapor or high humidity. Ambient temperature
should not exceed 131
°F (55°C). DO NOT
DO NOT
DO NOT
DO NOT
DO NOT locate
control cabinet near or adjacent to heat producing
equipment such as ovens, high wattage lamps,
etc. The area should be clean, dry and well
ventilated. If the transceiver is located remotely
from the rack assembly, the control cabinet should
be located such that the total length of the cable
between transceiver and rack assembly is no
longer than 40-feet.
>
The Serial Atomizer Module(s) MUST
MUST
MUST
MUST
MUST
be located outside the HAZARDOUS area
(See NFPA-33).
>
The user should be aware of, and
adhere to, all local fire codes and ordi-
nances.
>
Conduit MUST be used for the input AC
electrical connections
.
>
The user MUST provide a properly
fused disconnect between the power
source and the power supply which com-
plies with appropriate codes.
W A R N I N G
W A R N I N G
W A R N I N G
W A R N I N G
W A R N I N G
!!!!!
CONNECTIONS
CONNECTIONS
CONNECTIONS
CONNECTIONS
CONNECTIONS
(Refer to Figure 1)
(Refer to Figure 1)
(Refer to Figure 1)
(Refer to Figure 1)
(Refer to Figure 1)
Input power connections depend on the
motherboard used:
76913
78145
78147
Motherboard
Motherboard
Motherboard
Motherboard
Motherboard
Part #
Part #
Part #
Part #
Part #
J16
J8
J7
Connection
Connection
Connection
Connection
Connection
Points
Points
Points
Points
Points
Serial bus cable and transceiver assembly
connections (see Figure 2).
Pneumatic connection is made through the fittings
of the motherboard.
Make connections with 4mm or 5/32" OD tubing
(see Figure 2).
• Drive Air Pilot to Port 1
• Supply Air to Port 2
• Brake Air Pilot to Port 3
• Bearing Air Feedback to Port 4
The tubing for the drive air pilot from the mother-
board to the volume booster must be a minimum of
10-feet long.
The tubing from volume booster to bell (drive line)
should be 1/2" OD (3/8" ID) and from 3-way valve
to bell (brake line) should be 3/8" OD (1/4" ID). The
use of tubing sizes other than these may
compromise the Serial Atomizer Module's
performance. Although the atomizer inlet tubing
sizes may be smaller for the drive and brake air
lines, it is recommended to run the larger size
tubing as close to the applicator as possible
before converting the tubing size to fit the applicator.
