Serial Analog Module - Safety

AREA

Tells where hazards
may occur.

HAZARD

Tells what the hazard is.

SAFEGUARDS

Tells how to avoid the hazard.

Spray Area /

High Voltage Equip-

ment

This is a high voltage device that

can produce electrical arcs ca-

pable of igniting coating materials.

Parts being sprayed must be supported on convey-

ors or hangers and be grounded. The resistance

between the part and ground must not exceed 1

megohm. (Reference NFPA-33.)

A safe distance must be maintained between the

parts being coated and the atomizer bell. A distance

of at least 1-inch for each 10kV of power supply

output voltage is required at all times.

Parts must be supported so that they will not swing

and reduce the clearance specified above.

All electrically conductive objects in the spray area,

with the exception of those objects required by the

process to be at high voltage, must be grounded.

Unless specifically approved for use in hazardous

locations, the power supply and other electrical

equipment must not be used in Class I, Division 1

or 2 locations.
