Aerobell 168 - Maintenance
87
LN-9270-12.3
MAINTENANCE DISASSEMBLY PROCEDURES
(For Robot/Machine Mount Kits)
Step 19
Using the 5mm Hex Key
Wrench remove the five (5)
SHCS that secure the Mounting
Block to the Valve Manifold
There are different Mounting
Blocks for other applications.
Step 20
Step 21
By hand remove the three (3)
A12814-00 Tube Receivers.
