Page 101

Aerobell 168 - Parts
LN-9270-12.3
98
PARTS IDENTIFICATION
A13034 MACHINE MOUNT KIT (WITH VALVES)
3
1
3
2
4
3
3
3
3
PARTS LIST - MACHINE MOUNT VERSION
DESCRIPTION
PART NUMBER
QTY
ITEM
BRACKET ARM
A12789-00
2
1
BRACKET PIVOT
A12793-00
2
2
SCREW (M10 X 16MM LONG)
A12807-00
8
7
SCREW (M12 X 25MM LONG)
A12808-00
4
8
VALVE SEAT ASSEMBLY
77367-00
3
10
VALVE ASSEMBLY (NON-REPAIRABLE)
78949-00
3
11
MOUNTING BLOCK
A12912-00
1
36
TOP VALVE PLATE
A12818-00
1
37
TUBING GUIDE
A12825-00
1
38
CUP WASH Y FITTING
A12824-00
1
39
CUP WASH FERRULE
A12822-00
4
40
CUP WASH FITTING
A12821-00
4
41
TUBE FITTING (8 X 6) - PAINT,DUMP & SOL
A12816-00
3
42
TUBE FITTING (4 X 2.7) - (DP), (PT) & (ST)
A12815-00
3
43
TUBE RECEIVER (4 X 2.7) - (DP), (PT) & (ST)
A12814-00
3
44
O-RING, SOLVENT PROOF
79001-04
6
45
SCREW, SHCS M4 X 10MM LONG SS
A11119-10
2
46
SCREW, SHCS, M6 X 1.0 X 10MM, SS
A10468-10
3
47
SCREW, SHCS, M6 X 1.0 X 12MM, SS
A10468-12
7
48
TEFLON TUBING
A11252-01
19"
51
COILED FLUID TUBE
TABLE A
1
53
FITTING, FLUID
78449-00
1
54
FERRULE, BACK 1/4" TUBE
EMF-202-04
1
55
FERRULE, FRONT 1/4" TUBE
EMF-203-04
1
56
SET SCREW (CUP POINT M8 X 1.25 X 12MM SS)
A13030-00
1
61
MOUNTING YOKE
A12976-00
1
68
POST
A12977-00
1
69
VALVE MANIFOLD
A12790-00
1
70
TABLE A MACHINE MOUNT KIT OPTIONS W/FLUID TUBE
PART NO. COILED TUBE
DESCRIPTION
A13034-01 79879-00
MACHINE MOUNT W/TRIGGER, DUMP,CUP WASH AND
SOLVENT VALVES, & FLUID COIL (16 COILS) 1/4 OD X 1/8 ID
A13034-02 79879-01
MACHINE MOUNT W/TRIGGER, DUMP,CUP WASH AND
SOLVENT VALVES, & FLUID COIL (12 COILS) 1/4 OD X 1/8 ID
TORQUE T 15-20 LBS. - IN. (1.69 - 2.26 Nm) AFTER VALVE IS DOWN
TORQUE TO 15-20 LBS. - IN. (1.69 - 2.26 Nm)
TORQUE TO 5-10 LBS. - IN. (.56-1.13 Nm)
FINGER TIGHT UNTIL CLICK
1
2
3
4
