Section 1 - Boiler Specifications
2-1/2” MPT Supply
2-1/2” FPT Return
Clean-Out
Port
Clean-Out
Port
1
2
3
5
4
6
7
9
8
13
12
14
10
11
FRONT
SIDE
REAR
TOP
No.
Dimension
1
36"
2
33"
3
73-3/8"
4
12"
5
52"
6
8"
No.
Dimension
7
3/4"
8
9-3/8"
9
7-3/4" oc
10
18" oc
11
5" oc
12
29-1/2" oc
No.
Dimension
13
4" oc
14
20" oc
