GENERAL PUMP
A member of the Interpump Group
VH SERIES
Page 5
4. PUMP IDENTIFICATION
Each pump is fitted with a rating plate (see Fig. 1)
containing the following information:
2. pump model and version
3. serial number
4. max RPM
5. max operating pressure (bar)
6. oil capacity (ltr) and oil specification
7. max flow rate (l/min)
Pump model, pump version and serial number should
be specified when ordering spare parts. Should the pump
be modified (i.e by changing the original version) then
any change should be mentioned on the rating plate for
future reference.
5. TECHNICAL FEATURES
6. DIMENSIONS AND WEIGHT
MODEL RPM
FLOW RATE PRESSURE POWER
GPM l/min PSI Bar Hp kW
VH12 750 2.6 10 17,400 1200 30 22
VH14 750 3.6 14 14,500 1000 36.4 26.8
VH16 750 4.7 18 10,800 750 35 25.8
VHS16 1000 6 23 10,150 700 41.8 30.8
Weight: 185 lb.
