GENERAL PUMP
A member of the Interpump Group
VH SERIES
Page 16
REPAIR KITS
Item VH12 VH14 VH16 VHS16
35-36-37-39-40-43-61-62 F1096 F1097 F1098 F1098
49-51-61-62 F1099
3-6-10-14-15-23-32-33-35-36
37-39-40-43-49-51-61-62
F1100 F1101 F1102 F1102
Item Part # Description QTY.
1 F040000130 Lower cover 1
2 F871115153 Screw, M6 x 16 17-23
3 F881013100 O-ring Ø 20 x 2.5 2
4 F010100050 Hydraulic motor flange (Type A) 1
F010100040 Hydraulic motor flange (Type B) 1
5 F871125154 Screw M10 x 30 6
6 F881080014 Oil seal Ø 40 x 60 x 10 2
7 F911110002 Bearing 2
8 F063400100 Bearing cover 1-2
9 F801053002 Oil Level Indicator G 1/2” 1
10 F872043001 Aluminum washer Ø 3/8” 1
11 F801057001 Magnetic plug G 3/8” 1
12 F801053003 Oil level indicator G 3/4” 1
13 F063400120 Back cover 1
14 F080600000 Back cover gasket 1
15 F881011153 O-ring V 18 x 3 1
16 F801054002 Oil filling plug 1
17 F071000030 Crankshaft key 1
18 F050000030 Crankshaft 1
19 F871350002 Connecting rod screw 6
20 F812000002 Brass bearing 3
21 F040400010 Crankshaft end cap 1
22 F250001050 Piston guide assembly 3
23 F872138010 Retainer pin Ø 2.5 x 22 3
24 F071000020 Wrist pin Ø 20 3
26 F041200000 Wiper 3
27 F010200000 Plunger spacer 3
28 F124200090 Plunger VH12 3
F124200100 Plunger VH14 3
F124200110 Plunger VH/S16 3
29 F250000050 Connecting rod assembly 3
30 F060100340 Crankcase 1
F060100420 Crankcase (hydraulic) 1
31 F821203100 Plug G 1/8” inox 7
32 F872042000 Aluminum washer Ø 10 7
33 F881081002 Oil seal Ø 38 x 52 x 7 3
34 F033300000 Packing support ring nut VH12 3
F033300010 Packing support ring nut VH14 3
F033300020 Packing support ring nut VH/S16 3
35 F881030004 Seal ring VH12 3
F881030005 Seal ring VH14 3
F881030007 Seal ring VH/S16 3
36 F881010124 O-ring Ø 50.47 x 2.62 6
37 F881011056 O-ring Ø 4 x 2 9
38 F162200000 Cylinder VH12 3
F162200010 Cylinder VH14 3
F162200020 Cylinder VH/S16 3
39 F083500030 Cooling system tip 3
40 F881010125 O-ring Ø 56.82 x 2.62 3
Item Part # Description QTY.
43 F205000020 Pressure packing kit VH12 3
F205000030 Pressure packing kit VH14 3
F205000040 Pressure packing kit VH/S16 3
45 F031500000 Pressure packing retaining bushing VH12 3
F031500010 Pressure packing retaining bushing VH14 3
F031500020 Pressure packing retaining bushing VH/S16 3
46 F208004810 Valve assembly 3
47 F090200120 Suction valve spring 3
48 F082200130 Suction valve poppet 3
49 F080500020 Valve seat ring (suction side) 3
50 F081200410 Valve seat 3
51 F080500030 Valve seat ring (delivery side) 3
52 F082200140 Delivery valve poppet 3
53 F090200130 Delivery valve spring 3
54 F021300170 Delivery valve guide 3
55 F043500030 Manifold screw cover 8
56 680086 Conical seal 4
57 F064200230 Manifold 1
58 F871135973 Screw M14 x 200 Spec. 8
59 F871125956 Screw M10 x 30 Spec. 12
60 F063200100 Valve cover 3
61 F010500020 Antiextrusion ring 3
62 F881010200 O-ring Ø 18.64 x 3.53 Spec. 3
63 F801203031 Quick coupling G 3/8” (for Ø 10 hose) 1
