Installation Requirements and Instructions
PHYSICAL SPACE REQUIREMENTS:
See Safety Precautions for important information regarding the installation area.
The unit must be installed on a level concrete pad/floor and protected from the weather and freezing temperatures.
Approximate overall dimensions/space requirements are listed below. Additional space is required around and
above the equipment for loading and unloading, storage drums, access for maintenance, etc.
Equipment model(s)
Width
Depth
Height
LS-15E/15IIE
51 in. (1.3 m.)
27 in. (0.7 m.)
42 in. (1.1 m.)
LS-15E/15IIE + JetVac
108 in. (2.7 m.)
27 in. (0.7 m.)
48 in. (1.2 m.)
LS-55E/55IIE
75 in. (1.9 m.)
40 in. (1.0 m.)
60 in. (1.5 m.)
LS-55E/55IIE + JetVac
131 in. (3.3 m.)
40 in. (1.0 m.)
60 in. (1.5 m.)
IMPORTANT: If using a Little Cooler closed-loop cooling system with the Little Still, the Little Cooler must be
located outside of the hazardous area. Refer to the Little Cooler Instruction Manual for further details.
ASSEMBLY:
See Parts Location Diagram for additional information.
Remove the unit from the shipping containers and inspect for damage. If damage is detected, save all packaging
and immediately report any exterior or interior damage to the freight carrier.
Remove all accessories from the inside of the Still (and the JetVac’s cabinet, if applicable).
Install the pressure relief valve assembly into the top of the Still’s lid. Face the elbow towards the rear of the unit
(away from the occupied area).
Attach the supplied grounding cables/clamps to the ground block on the right side of the Still.
Thread the discharge hose into the discharge pipe on the right side of the Still. Omit this step if installing a JetVac
(see below).
SPECIAL ASSEMBLY FOR LS-15IIE AND LS-55IIE:
“System II” Stills have additional features for
automatic operation. Explanations of these features are discussed in the Instrumentation and Controls section.
Install the vapor temperature gage into the control panel on the front of the Still (this gage is a delicate instrument
and is packed separately to prevent damage). Attach the white wire to the positive (+) terminal and the red wire to
the negative (-) terminal. Mount the gage using the two nuts provided.
