SPARE PARTS - ELECTRICAL:

Item #

Part #

Description

Notes

C1 J101486

Contactor

Controls

heater in Still or pump in JetVac

CTRL1

J102795

Temp control board, LS-15E/55E

Controls cycle temperature from 100°F to 392°F.

CTRL1

J102734

Temp control board, LS-15IIE/55IIE

Controls cycle temperature from 100°F to 392°F.

FS1

J100914

Flowswitch, LS-55E/55IIE

Rated for 1½ gallons per minute.

FS2

J100913

Flowswitch, LS-15E/15IIE

Rated for ½ gallons per minute.

FUSE1

J102735

Fuse, System II

Protection for controls. Type 3AG 2A.

FUSE2

J102919

Fuse, System II (600 mA)

Protection for Power Supply. 250 volt 5 x 20mm

LT2

J102736

Indicator light, white, System II

Cooling water indicator.

LT3

J102737

Indicator light, amber, System II

Heat on indicator.

MOV1

J102738

MOV, System II

For surge protection.

MTR1

J103298

Motor, JetVac pump

X-proof, 3450 rpm, 56C, 208-230V/1 Ph, 60 Hz.

PB1/LT1

J100323

STOP/START switch, LS-15E/55E/JV

Pull on, push off switch with green light.

PB1/LT1

J102739

STOP/START switch, LS15IIE/55IIE

Pull on, push off switch with green light.

POT1

J102139

Potentiometer, System II cycle temp

For adjusting the cycle temperature, 450

.

POT2

J102740

Potentiometer, System II cycle time

For adjusting the cycle time, 1 M

.

PS1

J102741

Power supply, System II

Power supply converts 240 VAC to 24 VDC.

RC1/RC2

J101699

RC network assembly

RC network, crimp connectors.

SOL1

J100889

Solenoid valve, System II water

Controls the cooling water supply to the condenser.

SOL2

J102249

Solenoid Valve, JetVac relief

Vacuum relief valve. Opens when JV is off.

SSR1/SSR2

J102742

Relay, solid state, System II

For heater control and JetVac control.

TC1 J101157

Thermistor

Temperature

sensing probe for Still (Controlled by

POT 1 - 100

F to 392F ) K1 is its contact.

TC2 J101157

Thermistor

Overtemp sensing probe for still (412

F) K2 is its

contact.

TIM1

J102743

Timer relay, System II cycle time

16 hour timer for cycle time

TIM2

J102744

Timer relay, System II cool-down

1-hour timer for condenser water.

Note: Heater for LS-15E/15IIE is 1650 watts. Heater for LS-55E/55IIE is 6200 watts
