27
Appendix
SPARE PARTS - MECHANICAL:
Part # Description Notes
A100619 Aspirator, brass, JetVac Attaches to discharge of pump. Standard brass material.
A101047 Aspirator, stainless steel, JetVac Optional aspirator material. 316 SS construction.
J100634 Condenser, LS-15 Standard CuNi construction.
A100413 Condenser, LS-15 stainless steel Condenser with 316 SS construction.
J102937 Condenser, LS-55 Standard CuNi construction.
A100431 Condenser, LS-55 stainless steel Condenser with 316 SS construction.
A101126 Discharge hose Red Nycoil tubing with brass fitting.
A100416 Discharge hose with sightglass Nycoil hose, brass sightglass and swivel fitting.
J100205 Flame check-valve, JetVac Attached to rear of JetVac for venting of solvent vapors.
J100216 Heat resistant tape Tape used to help seal Still’s lid for better vacuum.
M100182 Lid Gasket, LS-15 Gortex rope for lid seal.
M100188 Lid Gasket, LS-55 Gortex rope for lid seal.
A100423 Lid toggle clamp Holds down lid.
A100439 Liftrack, LS-55 SS rack with handles used to help remove Stilbags.
J100221 Plastic Stilscraper For scraping the residues from vessel walls.
A100628 Pressure relief valve assy. - LS-15 Mounts in lid, rated for 1/2 psi.
A100587 Pressure relief valve assy. - LS-55 Mounts in lid, rated for 1/2 psi.
A100444 Pump reservoir, JetVac Stainless steel reservoir - tank only.
J100211 Quick connector, female Attach to Still for easy connection of braided hose.
J100210 Quick connector, male Attach to braided hose for easy connection to Still.
A101436 Quick-cool tube assy. Internal PTFE tubing and fittings for Q-cool. 2 req’d.
M100184 Reservoir lid gasket, JetVac Gortex gasket for sealing pump reservoir cover.
M100115 Seal, JetVac motor shaft Lip seal used on pump motor to protect bearings.
A100445 SS cooling coil, JetVac Includes mounting plate, and gasket. Three required.
A100576 Static ground clamp (6’) Braided wire with alligator-type clip and ring connector.
M101055 Stilbag ring, LS-15 Holds Stilbag in place.
A100438 Stilbag ring, LS-55 Holds Stilbag in place.
M101831 Stilbags, LS-15 hi temp, per doz. Rated for temperatures up to 430 F (blue).
M101830 Stilbags, LS-15 reg. temp, per doz. Rated for temperatures up to 400 F (clear).
M101833 Stilbags, LS-55 hi temp, per doz. Rated for temperatures up to 430 F (blue).
M101832 Stilbags, LS-55, reg. temp, per doz. Rated for temperatures up to 400 F (orange).
A100427 Stilpan, LS-15 Non-stick coated pan for residue removal without bags.
A100440 Stilpan, LS-55 Non-stick coated pan for residue removal without bags.
A100414 Thermowell for standard condenser. Threads into condenser for vapor temperature gage.
J100212 Vacuum gage Measures vacuum level in inches of Hg.
J100209 Vacuum hose, metal braid, JetVac Hose between JetVac and discharge of still.
A100442 Vacuum pump assembly Includes housing, impeller assy., and center bearing.
M100176 Vapor temperature gage Measures vapor temp at condenser.
... . ..
.
