17 6
S A F E T Y I N S T R U C T I O N S (continued)
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design. All operators of this equipment must read and understand this entire manual, pay-
ing particular attention to safety and operating instructions, prior to using. If there is something in this manu-
al you do not understand, ask your supervisor, or your dealer, to explain it to you.
OPERATIONAL SAFETY
Do not reach or place yourself under equipment until it is blocked securely.
Take all possible precautions when leaving unit unattended: Disengage PTO, set parking brake, stop engine
and remove key from ignition. Park in level area.
Do not allow riders on the rear blade or tractor at any time. There is no safe place for any riders.
Never operate tractor and implement under trees with low hanging limbs. Operators can be knocked off the
tractor and then run over by the implement.
Use extreme care and maintain minimum ground speed when transporting on hillside, over rough ground and
when operating close to ditches or fences. Be careful when turning sharp corners.
Reduce speed on slopes and sharp turns to minimize tipping or loss of control. Be careful when changing
directions on slopes. Do not start or stop suddenly on slopes. Avoid operation on steep slopes.
When using a unit, a minimum 20% of tractor and equipment weight must be on tractor front wheels. Without
this weight, tractor could tip over, causing personal injury or death. The weight may be attained with a front
end loader, front wheel weights, ballast in tires of front tractor weights. When attaining a minimum 20% of trac-
tor and equipment weight on the front wheels, you must not exceed the ROPS weight certification. Weigh the
tractor and equipment. Do not guess or estimate!
Inspect the entire machine periodically as indicated in the Maintenance Section of this manual. Look for loose
fasteners, worn or broken parts, pinched hydraulic hoses, and leaky or loose fittings. Make sure all pins have
cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
Stay alert for holes, rocks and roots in the terrain and other hidden hazards. Keep away from drop-offs.
In extremely uneven terrain, real wheel weights, front tractor weight, and/or tire ballast should be used to
improve stability.
Pass diagonally through sharp dips and avoid sharp drops to prevent “hanging up” tractor and implement.
Practice will improve your skills in maneuvering rough terrain.
Always cut down slopes; never across the face. Avoid operation on steep slopes. Slow down on sharp turns
and slopes to prevent tipping and/or loss of control.
W A R N I N G !
▲ Lower blade to ground or block securely, turn
tractor engine off, remove key and set brakes or
place shift lever in “Park” position.
▲ Before working underneath, raise 3-pt. hitch to
highest position and block blade securely.
Hydraulic system leakdown and failure of
mechanical or hydraulic system can cause
equipment to drop.
▲ Keep all persons away from operator control
area while performing adjustments, service or
maintenance.
▲ Do not run engine indoors – exhaust gases
contain carbon monoxide, an odorless and
deadly poison.
T R A N S P O RT I N G
Pay particular close attention to the Safety Messages
regarding transport. Avoid unnecessary injuries and
equipment damage by exercising cautious, conscien-
tious travel procedures.
Attaching the blade to the tractor increases the overall
length of the working unit. Allow additional clearance for
the blade to swing when turning.
Raise the blade as high as possible for transporting.
Always transport blade with blade centered on tractor.
Never attempt road travel with blade offset into the traffic
lane.
M A I N T E N A N C E
Inspect the blade for loose, damaged or worn parts and
adjust or replace if needed.
Repaint parts where paint is worn or scratched to
prevent rust.
Check all bolts and nuts to be sure they are tight.
At the end of the working season or when the blade will
not be used for a long period, it is good practice to clean
off any dirt that may have accumulated on the blade and
any of the moving parts.
Lubricate front swing arm pivot pin.
S T O R I N G S A F E LY
• Never store equipment with fuel in the tank inside a
building where fumes may reach an open flame or
spark. Allow engine to cool before storing in an
enclosure.
• Always store blade in a clean, dry location away from
children and livestock.
• Storage location should be level and solid to make
hitching and unhitching easy.
O P T I O N S
O W N E R S E RV I C E
SAFETY . . .
YOU CAN LIVE WITH IT!
MODEL SK-6 SKID SHOE INSTALLATION
Attach the skid shoe mounting bracket to the 2nd and
3rd cutting edge holes from each end of the moldboard.
Insert the skid shoe in the mounting bracket and secure
with the
1 / 2 ” – 13NC x 1 1 / 2 ” long square head set screw
and jam nut. Be sure the skid shoes are turned so the
adjustment holes match the point of the set screw. See
parts illustration.
MODEL EP-38 END PLATE INSTALLATION
The end plates mount to the inside of the blade using
the end cutting edge hole and the hole in the moldboard
directly above it. Replace the cutting edge bolt with the
longer
5 / 8 ” – 11NC x 2” long carriage bolt provided. On
earlier models it may be necessary to match drill the
upper
11 / 16 ” Dia. hole in the moldboard. Install the upper
5 / 8 ” – 11NC carriage bolt. See parts illustration.
