1 power supply, 2 keypad description, Set tare zero – Fairbanks DPB Series Scale Store User Manual
Page 7
06/10
7
50701 Rev. 2
Section 2: Features
1-1 POWER SUPPLY
1. The power switch is located on the bottom of the scale on the right side.
2. The power supply is AC 110V or AC 200V ±10%, 50/60 HZ
1-2 KEYPAD DESCRIPTION
50701-1
THE SCALE STORE
ON
OFF
CHANGE
SET
TARE ZERO
WEIGHT
MODE
TARE SET
DPB 12W
W E I G H T
ON
OFF
CH
SET
TARE ZERO
MODE
TARE SET
DPB 65
THE SCALE STORE
