A. Unpacking:
Check that all parts are included using the packing list.
Check for component damage that may have occurred during shipping.
B. Assembly:
Caution: The scale base assembly, as shipped, weighs 105 lbs.,
use caution when lifting.
1. Wheel and Pillar Assembly
Note: The descriptions below refer to "Item No" to describe parts. Use
the parts list and Item # in the list to identify those parts.
a. Set the scale base assembly (#4) upright on the floor.
b. Starting with an axle (#19), insert a cotter pin (#17) in 1
end, then place 1 washer (#18) & 1 wheel (#16) over the
open end.
c. Insert the axle's other end through BOTH holes in the base.
d. Place a wheel (#16), then 1 washer over the other end
and insert a cotter pin.
e. Repeat steps 2-4 for the 2nd axle.
f. 'Center' the axles in the base, then insert the locking
screws (#15) into the tapped holes in the bottom of the
base (directly under the axle holes).
g. Tighten the locking screws, then secure the lock nuts (#14).
03/13 6 50595 Rev. 6
Section 3: Installation
