Appendix i: load cells – Fairbanks 3500 Series Yellow Jacket User Manual
Page 22
11/10
22
51233 Rev. 4
Appendix I: Load Cells
ITEM
PART NO.
DESCRIPTION
SCALE
CAPACITY
2 30238
1K lb Capacity Load Cell
350 Ohm, 3 mV/V, Plated Tool Steel
2.5k
2
30239
2.5K lb Capacity Load Cell
350 Ohm, 3 mV/V, Plated Tool Steel
5k
WIRE COLOR
FUNCTION
Black (─) Excitation
Red (+)
Excitation
Yellow Shield
Green (+)
Signal
White (─)Signal
