AT-9748TS/XP | Managed L3 Stackable Gigabit Ethernet Switch w/10GbE Uplinks
Security
RADIUS Authentication
Support IEEE 802.1x Port-based Access Control
Support IEEE 802.1x MAC-based Access Control
SSH
TACACS/TACACS+ Authentication
SSL
Support Cisco-like Port Security
Access Control List support (ACL):
- 8 Profiles
- 50 Rules
Based on:
- MAC address
- VLAN
- IP address
- Protocol Type
- TCP/UDP port number
- IEEE 802.1p
- DSCP
- Port
- TCP/UDP payload
MIB Support
RFC 1213 MIB II
RFC 1493 Bridge
RFC 1757 RMON
RFC 1643 Ether-like MIB
Private MIB
RFC 2674 IEEE 802.1p
IF MIB
RFC 2233 Interface MIB
IGMP MIB
RIP MIB
RFC 1850 OSPF
RFC 2096 CIDR MIB
RFC 2096 IP Forwarding Table MIB
Physical Characteristics
Height: 4.4cm (1.7”)
Width: 44cm (17.3”)
Depth: 43.1cm (17.0”)
Weight: 6.412kg
Mounting: 19" rack-mountable, hardware incl.
Standards & Compliance
IEEE 802.3 10T Ethernet
IEEE 802.3u 100TX Ethernet
IEEE 802.3ab 1000T Ethernet
IEEE 802.3ae 10GbE
IEEE 802.3z 1000X Ethernet
IEEE 802.3ad Link Aggregation
IEEE 802.1d Spanning Tree
IEEE 802.1p Class of Service, priority protocols
IEEE 802.1Q VLAN Tagging
IEEE 802.3x Flow Control
RFC 1112 IGMP Snooping v1
RFC 2236 IGMP Snooping v2
RFC 951 BootP
RFC 2131 DHCP
RFC 1350 TFTP
RFC 1757 RMON Groups 1, 2, 3 and 9
TACACS+
RADIUS
RIP v1 & v2
RFC 1850 OSPF
VRRP
DVMRP
PIM Dense Mode and PIM Sparse Mode
IGMPv2
GARP/GVRP
Electrical/Mechanical
Power Consumption: 143W
Power Characteristics:
Voltage: 100-240V AC auto-ranging
Frequency: 50-60Hz
Environmental Specifications
Operating Temp 0˚C – 40˚C (32˚F – 104˚F)
Storage Temp -25˚C – 55˚C
Relative Humidity Range 5% – 95% non-condensing
Approvals
UL 1950
FCC Class A
CSA 22.2 No. 950
EN55022 Class A
EN 60950 (TUV)
EN50082-1
CE
Country of Origin
Taiwan
Stacking Function
Ring Stacking with up to 8 AT-9748TS/XP through 2
stacking ports in the rear providing 40Gbps stacking
bandwidth Management Support
Ordering Information
AT-9748TS/XP-20
48 port 10/100/1000TX stackable layer 3+ Gigabit
Ethernet switch + 4 SFP Combo and 2 x 10GbE
uplink option
With:
• Three power cords (US, UK, European)
• Stacking cable.
• Two year warranty
AT-XP9700
2 x 10Gb uplink module with 2 x XFP slots
AT-RPS9700-xx
2-slot Redundant PSU frame for AT-9700 Series
AT-PWR9700-xx
PSU modules for AT-RPS9700 (max 2)
AT-XPSR (10GbE XFP)
850nm, 300m, multimode fiber
AT-XPLR (10GbE XFP)
1310nm, 10km, singlemode fiber
AT-SPSX
Multimode Fiber, GbE Small Form Factor Pluggable
(SFP), 500m, 850nm
AT-SPLX10
Singlemode Fiber, GbE Small Form Factor Pluggable
(SFP), 10km, 1310nm
AT-SPSLX40
Singlemode Fiber, GbE Small Form Factor Pluggable
(SFP), 40km, 1310nm
AT-SPLX40/1550
Singlemode Fiber, GbE Small Form Factor Pluggable
(SFP), 40km, 1550nm
AT-SPZX80/xxxx
Singlemode Fiber, GbE Small Form Factor Pluggable
(SFP), 80km, 1550nm
