TWO COLUMN 8K FLOOR PLATE LIFT CO7589 IN50014 Rev. D 03/2/2010 2
TABLE OF CONTENTS
• IMPORTANT INFORMATION..................................................................... 2
• GENERAL LIFT INFORMATION / FEATURES.......................................... 2
• LIFT
SPECIFICATIONS:............................................................................. 4
• LIFT AREA LAYOUT INFORMATION........................................................ 6
• FOUNDATION and ANCHORING REQUIREMENTS ................................ 7
• TOOLS and EQUIPMENT REQUIRED for INSTALL ................................ 8
• INSTALLATION
PROCEDURE .................................................................. 9
• OWNER / EMPLOYER RESPONSIBILITIES ............................................. 15
• LIFT
LOCKOUT/TAGOUT .......................................................................... 16
• SAFETY PROCEDURES ............................................................................ 17
• LIFT OPERATION....................................................................................... 19
• PREVENTIVE MAINTENANCE SCHEDULE ............................................. 20
• TROUBLESHOOTING ................................................................................ 22
• ILLUSTRATED
PARTS BREAKDOWN ..................................................... 24
• PARTS LIST................................................................................................ 28
IMPORTANT INFORMATION
Two Post Lifts
1. Any freight damage must be noted on the freight bill before signing and reported to the freight carrier
with a freight claim established. Identify the components and check for shortages. If shortages are
discovered, please contact the Distributor / Sales Rep. in your area for service.
2. Consult building owner and / or architect’s plans when applicable to establish the best lift location. The
lift should be located on a relatively level floor with 4 in. minimum thickness, 3000-psi concrete slab
that has been properly cured. There can be no cracks in the slab within 36 in. of the base plate
location, and no seams in the foundation within 6 in. of its location! Remember: any structure
is only as strong as the foundation on which it is located!
IMPORTANT! Make sure you have extra help or heavy duty lifting equipment when
unloading and assembling the lift.
3. Please read the safety procedures and operating instructions in this manual before operating lift. Keep
this manual near lift at all times. Make sure all operators read this manual.
4. The lift should be located on a relatively level floor of less than 3 degrees slope. If slope is
questionable, consider a survey of the site and/or the possibility of pouring a new level concrete slab.
5. Make sure you have enough area and ceiling height to install lift. (See Lift Specifications)
6. Never raise a car until you have double checked all bolts, nuts and hose fittings.
7. Always lower the lift onto the locks before going under the vehicle. Never allow anyone to go under
the lift when raising or lowering.
This is a vehicle lift installation/operation manual and no attempt is made or implied herein to
instruct the user in lifting methods particular to an individual application. Rather, the contents of
this manual are intended as a basis for operation and maintenance of the unit as it stands alone
or as it is intended and anticipated to be used in conjunction with other equipment.
Proper application of the equipment described herein is limited to the parameters detailed in the
specifications and the uses set forth in the descriptive passages. Any other proposed
application of this equipment should be documented and submitted in writing to the factory for
examination. The user assumes full responsibility for any equipment damage, personal injury, or
alteration of the equipment described in this manual or any subsequent damages.
