Air Operated Double Diaphragm Pump 6/05 Page 2
TYPICAL CODE=
Model - X75
Design Level
Wetted Components
A: Aluminum
C: Cast Iron
S: Stainless Steel
Non-Wetted Components
A: Aluminum
C: Cast Iron
S: Stainless Steel
Check Valve Type
B: Solid Ball
W: Weighted Ball
Suction Orientation
B: Bottom
X75. 01. A A. B B.
Valve Seats
A: Aluminum
C: Carbon Steel
S: Stainless Steel
N: Neoprene
B: Buna N
E: EPDM
V: Viton
®
T: PTFE
Check Valves
T: PTFE
B: Buna N
N: Neoprene
E: EPDM
S: Santoprene
Diaphragms
T: PTFE
B: Buna N
R: Santoprene
®
V: Viton ®
E: EPDM
B B B
Maximum delivery: 567 ltrs/min
Max. working pressure: 8.6 bar
Max. solid particle size: 6mm
Air inlet: 3/4" BSP (Parallel, Internal)
Temperature limits: Determined by elastomers
Fluid inlet/outlet: 3" BSP (Parallel, Internal) Installation: Surface mounted
Accessories included: Exhaust air silencer
Shipping weights with
Aluminum mid sections: A: 52kg
C: 98kg
S: 87kg
Shipping dimensions: 560x430x690mm
II 2GD T5
II 1G c T5
II 3/1 G c T5
II 1D c T100°C
I M1 c
I M2 c
II 2G c T5
II 3/2 G c T5
II 2D c T100°C
Models equipped with Wetted Options
C or S , Non-Wetted Options C or S.
Note: See page 23 EC-Type Certificate.
Models equipped with Wetted Options A, C
or S, Non-Wetted Options A, C or S.
Note: See page 23 Type Examination
Certificate.
Nitrile
Nitrile
Nitrile
FKM
FKM
R
- C
C: Center Ported*
N: NPT Threads
*Available with Stainless Steel equipped models ONLY.
3” BSP Tapered Center-Port Stainless Steel ONLY
3” NPT Center-Port Stainless Steel ONLY
