x25fvdl2sm-rev0213

1

• Model X25 Metallic

www

.

blagdonpump

.

com

Explanation of Pump Nomenclature

TYPICAL CODE=

X25. 02. C. C. F. T. B. B.

S. - N

Model - X25

Design Level

Non-Wetted Components

A: Aluminum

C: Cast Iron

Wetted Components

A: Aluminum

C: Cast Iron

S: Stainless Steel

Valve Type

F: Flap

Suction Orientation

T: Top

Valve Seats:

S: Stainless Steal

Options:

N: NPT Pipe Threads

CP: Center Port

Flap Valves

B: Nitrile

N: Neoprene

R: Santoprene

P: Polyurethane

H: Hytrel

V: FKM

E: EPDM

Diaphragms

B: Nitrile

R: Santoprene

N: Neoprene

V: FKM

E: EPDM

H: Hytrel

Cast Iron mid sections: C: 29

S: 30

Maximum delivery: 265 ltrs/min

Max. working pressure: 8.6 bar

Max. solid particle size: 25mm

Air inlet: 1/2” NPT

Temperatur limits: Determined by elastomers

Fluid inlet/outlet: 1" NPT or 1" BSP Tapered

Intallation: Surface mounted

Accessories included: Metal Exhaust air silencer

Shipping weights with

Aluminum mid sections: A: 52kg

B: 23kg

C: 24kg

II 2GD T5

II 1G c T5

II 3/1 G c T5

II 1D c T100°C

I M1 c

I M2 c

Models equipped with Wetted

Options

C or S , Non-Wetted Options C.

Note: EC-Type Certificate.

II 2G c T5

II 3/2 G c T5

II 2D c T100°C

Models equipped with

Aluminium components

Note: Type Examination

II 2GD T5

II 2GD T5

MODEL SPECIFIC

1: PUMP

SPECS
