2 - 1 6 2 - 1 6 2 - 1 6 2 - 1 6 2 - 1 6 C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n
2.5.3 2.5.3 2.5.3 2.5.3 2.5.3 Interrupt assignments Interrupt assignments Interrupt assignments Interrupt assignments Interrupt assignments
Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments
I R Q I R Q I R Q I R Q I R Q P r i o r i t y P r i o r i t y P r i o r i t y P r i o r i t y P r i o r i t y S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n
0 1 System Timer
1 2 Keyboard Controller
2 — Re-direct to IRQ #9
3 11 Reserved
4 12 Communications Port (COM1)*
5 13 IRQ holder for PCI steering*
6 14 Floppy Disk Controller
7 15 Printer Port (LPT1)*
8 3 System CMOS/Real Time Clock
9 4 IRQ holder for PCI steering*
10 5 IRQ holder for PCI steering*
11 6 IRQ holder for PCI steering*
12 7 PS/2 Compatible Mouse Port*
13 8 Numeric Data Processor
14 9 Primary IDE/SATA Channel
15 10 Secondary IDE/SATA Channel
* T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s .
When using PCI cards on shared slots, ensure that the drivers support
“Share IRQ” or that the cards do not need IRQ assignment; otherwise,
conflicts will arise between the two PCI groups, making the system
unstable and the card inoperable.
IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard
A A A A A B B B B B C C C C C D D D D D E EE EE F FF FF G G G G G H H H H H
PCI slot 1 — — — — shared shared shared shared
PCI slot 2 — — — — shared shared shared shared
IEEE 1394a — — — — — — shared —
LAN (88E8001) — — — — — shared — —
PCI-E x1_1 shared shared shared shared — — — —
PCI-E x1_2 shared shared shared shared — — — —
PCI-E x16_1 shared shared shared shared — — — —
PCI-E x16_2 shared shared shared shared — — — —
USB 1.0 controller 1 — — — shared — — — —
USB 1.0 controller 2 — — — shared — — — —
USB 1.0 controller 3 — — — shared — — — —
USB 1.0 controller 4 — — — shared — — — —
USB 2.0 controller — — — shared — — — —
HD audio shared — — — — — — —
SATA JMB360 shared shared shared shared — — — —
On-board SATA — — — — — shared — —
