Mounting and Shaft Connection
Specifications
The shaft can be coupled to the machine using a chain and sprocket, timing pulley and
belt, or a direct in-line shaft-to-shaft coupling.
If a shaft-to-shaft coupling is used, Electro Cam Corp. recommends the use of a flexible
coupling. Flexible couplings available through Electro Cam Corp. are listed on the Rotary
Cam Switch Price List, Lit. #111.
Using a solid coupling with shaft misalignment greater than 0.005" (T.I.R.) may
damage the unit. Because of tolerance stackups, this will require shimming of the
individual unit to its mounting surface.
Output Module Specifications
The EC-3000 Series and the EC-3400 Series units offer plug-in modules for DC, AC, and Reed Relay outputs. One output
module must be purchased for each output desired. For further information, please consult the factory.
Max Speed: 3000 RPM, clockwise or counterclockwise rotation
Max Phase Shift: 1
°
/1000 RPM
Ambient Temp: 0
°
to 60
°
C (32
°
to 140
°
F)
Input Voltage: 120 VAC (108 to 132 VAC), 50 or 60 Hz.
12 VDC, 24 VDC or 240 VAC units available
Input Power: EC-3004/EC-3404 3 VA Max
EC-3008/EC-3408 6 VA Max
EC-3012/EC-3412 6 VA Max
Shaft: 3/4" diameter shaft extensions. The shaft is rated at 32,000 PSI yield and necked down to 0.500"
internally. Power transmission through shaft should be based on these figures.
Max Side Load: 100 lbs. at speeds up to 1800 RPM / 200 lbs. at speeds up to 500 RPM
Bearing Life: 10 years (87,660 hours) continuous running with 75 lbs. side load at 1000 RPM
Note: Consult factory if higher speeds or larger loads are required.
Enclosures: EC-3000—NEMA 12 steel housing
EC-3400—NEMA 4X stainless steel housing
Printed Circuit
Board:
EC-3000—conformal coating on top only
EC-3400—conformal coating on top and bottom
Net Weight: EC-3004/EC-3404: 9.0 lbs. 4.0 kg
EC-3008/EC-3408: 13.5 lbs. 6.1 kg
EC-3012/EC-3412: 15.0 lbs. 6.8 kg
DC Output: EC-ODC5A, Red
Output Voltage: 0 to 200 VDC
Output Current: 0.5 Amp
Derate .018 amp/
°
C above 45
°
C (113
°
F)
AC Outputs: EC-OAC5A-11, Black/Gray
Output Voltage: 24 to 132 VAC
Output Current: 0.8 Amp @ 35
°
C (95
°
F)
Derate 50 mA/
°
C above 35
°
C (95
°
F)
Reed Relay: EC-ORR5, White
Output Type: Reed Relay Contacts
DC Rating: 0 to 24 VDC
0 to 100 mA DC (resistive loads only)
AC Rating: 0 to 120 VAC
0 to 30 mA AC (resistive loads only)
DC Output: EC-ODC5, Red
Output Voltage: 0 to 60 VDC
Output Current: 1.0 Amp @ 35
°
C (95
°
F)
Derate 35.7 mA/
°
C above 35
°
C (95
°
F)
