Appendix A Model 6400EH
Teledyne Analytical Instruments 78
NAME DESCRIPTION UNITS
ZSCNC1
SO
2
concentration for range #1 during
zero/span calibration, just before computing
new slope and offset PPB
ZSCNC2
SO
2
concentration for range #2 during
zero/span calibration, just before computing
new slope and offset PPB
CONC1 SO
2
concentration for range #1 PPB
CONC2 SO
2
concentration for range #2 PPB
STABIL SO
2
concentration stability PPB
STRLGT Stray light reading PPB
RCTEMP Reaction cell temperature ° C
PMTTMP PMT temperature ° C
SMPFLW Sample flow cc/m
SMPPRS Sample pressure “Hg
VACUUM Vacuum pressure “Hg
BOXTMP Internal box temperature ° C
HVPS High voltage power supply output Volts
TEST8 Diagnostic test input (TEST_INPUT_8) mV
TEST11 Diagnostic test input (TEST_INPUT_11) mV
TEMP4
Diagnostic temperature input
(TEMP_INPUT_4)
° C
TEMP5
Diagnostic temperature input
(TEMP_INPUT_5)
° C
TEMP6
Diagnostic temperature input
(TEMP_INPUT_6)
° C
REFGND Ground reference (REF_GND) mV
RF4096 4096 mV reference (REF_4096_MV) mV
