Installation Model 3300ZB
Teledyne Analytical Instruments 10
3.2 Location and Mounting
3.2.1 Control Unit Installation
The 3300ZB control unit is designed to be wall-mounted in a
general purpose, indoor area, away from moisture and the elements. The
unit should be installed at viewing level in a sheltered area.
CAUTION: FOR THE DC POWERED VERSION, THE CONTROL
UNIT CHASSIS MUST BE ISOLATED FROM THE
INPUT POWER GROUND.
Refer to the Outline Diagram for the physical dimensions of the
analyzer, which can be found at the back of the manual.
3.3 Electrical Connections
Figure 3-1 shows the Model 3300ZB rear panel.
Primary Input Power: The power cord receptacle, fuse block and
power switch are located in the same assembly. A 6-foot standard AC
power cord is supplied with the control unit. Insert the female plug end
of the power cord into the power cord receptacle.
The universal power supply allows direct connection to any 100-
240VAC, 50/60 Hz power source. The fuse block, to the right of the
power cord receptacle, accepts a 5
 20 mm, 0.5A time-delay fuse (see
Fuse Replacement in Chapter 5 - Maintenance).
The power switch is located on the right-hand end of the power
source input receptacle assembly.
