1-1
Percent Oxygen Analyzer Introduction 1
Teledyne Analytical Instruments
Introduction
1.1 Overview
The Teledyne Electronic Technologies Analytical Instruments (TETAI)
Model 3300PB is a microprocessor-based percent oxygen analyzer for real-
time measurement of the percent of oxygen in inert gases, or in a wide variety of
gas mixtures. It features simple operation, fast response, and a compact, rugged
construction. Typical applications of the Model 3300PB are monitoring nitrogen
generators and inert gas blanketing applications.
1.2 Main Features of the Analyzer
The main features of the analyzer include:
• High resolution, accurate readings of oxygen content from 0-1 %
through 0-25 %, with 0-100% range optional. Large, bright, light-
emitting-diode meter readout.
• Simple pushbutton controls.
• Nylon cell holder.
• Advanced Micro-Fuel Cell, for percent analysis, has a two year
warranty and an expected lifetime of four years.
• Unaffected by oxidizable gases.
• Fast response and recovery time.
• Microprocessor based electronics: 8-bit CMOS microprocessor
with on-board RAM and 16 KB ROM.
• Two user selectable ranges (from 0-1 % through 0-25 %) allow best
match to users process and equipment.
• Air-calibration range for convenient spanning at 20.9 %.
