Teledyne 3300PA - Low cost percent oxygen analyzer User Manual
Page 35
A-3
Percent Oxygen Analyzer
Appendix
Teledyne Analytical Instruments
A.3
Reference Drawing
D-69127
Final Assembly (and interconnection diagram)
D-69220
Outline Diagram
A.4
Miscellaneous
The symbol: ~ is used on the rear panel of the model 3300PA to signify
volts alternating current (V ac).
NOTE:
The MSDS on this material is available upon request
through the Teledyne Environmental, Health and
Safety Coordinator. Contact at (626) 934-1592
