1-4
1 Introduction Model 3300 PA
Teledyne Analytical Instruments
• Power Connection 100–240 V ac, at 50/60 Hz. The connector
housing includes the fuse holder and the
power switch.
Fuse Holder: Replacing the fuse is
described in Chapter 5, Maintenance.
I/O Power Switch: Turns the instrument
power ON (1) or OFF (0).
• Analog Outputs 0–10 V dc concentration output.
0–10 V dc range ID (or optional overrange)
output.
4–20 mA dc concentration output, negative
ground.
• Alarm Connections Alarm 1, Alarm 2, and Sensor Failure Alarm
connections.
• Sensor Connector Internal Sampling System, Sensor
Connector.
