A-2
P P P P Per er er er ercent Oxyg cent Oxyg cent Oxyg cent Oxyg cent Oxygen Anal en Anal en Anal en Anal en Analyz yz yz yz yzer er er er er Appendix Appendix Appendix Appendix Appendix
Teledyne Analytical Instruments
Recommended Spare Parts List Recommended Spare Parts List Recommended Spare Parts List Recommended Spare Parts List Recommended Spare Parts List
Qty Qty Qty Qty Qty Part No Part No Part No Part No Part No Description Description Description Description Description
1* B-29600 PCB: E to I Converter, Isolated (O Option) (not 327RAC)
1* B-14702 PCB: E to I Converter, Neg Gnd (I Option) (not 327RAC)
1* A-9309 PCB: Alarm Comparator (-2 Option) (not 327RAC)
1* B-43812 PCB: Cell Failure Alarm (not 327RAC)
1* A-9306 PCB: Power Supply (used with above options) (not 327RAC)
1 B-30868 PCB: Temperature Controller (326RA/RB or 328R only)
1 A-9348 PCB: Oxygen Amplifier (All Models)
1 B-43812 PCB: Cell Failure Alarm (326RA/RB, 327RA/RB only)
1 T-176 Thermoswitch (327RA/RB only)
5 F-9 Fuse: 3AG, 1 Amp (220 V ac models only)
5 F-10 Fuse: 3AG, 2 Amp (110 V ac models only)
5 F-527 Fuse: 1/4 Amp
1 H-28 Heater (110 V ac models only)
1 H-34 Heater (220 V ac models only)
1 C-6689 Micro-Fuel Cell: Class **
1 A-7023 Cell Contact Spring (All except CENELEC)
1 A-6544 Cell Contact Pin (All except CENELEC)
1 A-33748 Thermistor Assembly (326RA/RB, 328R only)
1 T-366 Thermistor (327RAC only)
1 S-81 Triac (327RA/RB only)
1 D-186 Dial
1 M-41 Meter
1 P-156 Potentiometer: 10 k ohms
1 T-288 Transformer
* Optional item. Required only for instruments incorporating the option.
Any of these also require an A-9306 PCB.
EXCEPTIONS: All standard in 328RC. None available in 327RAC.
** Per Sales Order. See Specific Application Data in front of Table of
Contents.
A MINIMUM CHARGE OF $15.00 IS APPLIED TO SPARE PARTS
ORDERS.
IMPORTANT IMPORTANT IMPORTANT IMPORTANT IMPORTANT: Orders for replacement parts should include the part number : Orders for replacement parts should include the part number : Orders for replacement parts should include the part number : Orders for replacement parts should include the part number : Orders for replacement parts should include the part number
(if available) and the model and serial number of the system (if available) and the model and serial number of the system (if available) and the model and serial number of the system (if available) and the model and serial number of the system (if available) and the model and serial number of the system
for which the parts are intended.
for which the parts are intended. for which the parts are intended. for which the parts are intended. for which the parts are intended.
