38
SECTION IX
BURNER and BASKET (TUMBLER)/LINT CHAMBER
MANUAL RESET HI-LIMIT INSTRUCTIONS
(FOR PHASE 6 MODELS)
This dryer was manufactured with a burner manual reset hi-limit and basket (tumbler)/lint chamber
hi-limit thermostat, which is monitored by the Phase 6 computer. If either manual reset thermostat is open prior
to start of the drying cycle, the dryer will start momentarily and then shut down, the Phase 6 computer will
display an error code with an audio indication. If the basket (tumbler)/lint chamber hi-limit thermostat is open,
the display will read, “dRUM SAFETY FAIL.” If the burner hi-limit thermostat is open, the display will read
“bURNER SAFETY FAIL.”
If either manual reset hi-limit thermostat opens during a drying cycle, the display will show the
applicable error code described above along with an audio indication. If the drum temperature is above
100° F (38° C), the dryer will continue to run with no heat for 3 minutes or until the drum temperature has
flattened below 100° F (38° C). The STOP/CLEAR button on the Phase 6 keyboard (touch pad) must be
pressed to clear the error condition. The open manual reset hi-limit thermostat must be reset “manually” prior
to the start of the next cycle.
This hi-temperature condition may be caused due to a restricted exhaust, poor airflow, or improper
burner operation.
The location of the burner hi-limit is on the right side of the burner box and the basket (tumbler) hi-limit
is located in the lint chamber area.
WARNING: Discontinue power to dryer before attempting to reset hi-limit.
IMPORTANT
This dryer is equipped with a burner
hi-limit and tumbler/lint chamber hi-limit
thermostat which must be reset manually.
WARNING: Discontinue power to dryer
before attempting to reset hi-limit.
ADC P/N:114093
