6
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
IMPORTANT: Dryer must be supplied with clean, dry, and regulated air pressure at 80 PSI ± 10
PSI (5.51 bars ± 0.68 bars).
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
GAS
MAXIMUM CAPACITY (DRY WEIGHT) 95 lbs. 43.1 kg
BASKET (TUMBLER) DIAMETER 42" 106.7 cm
BASKET (TUMBLER) DEPTH 29-1/4" 74.3 cm
BASKET (TUMBLER) MOTOR 1/2 HP 0.373 kw
BLOWER MOTOR 3 HP 2.238 kw
DOOR OPENING (DIAMETER) 30-3/4" 78.1 cm
BASKET (TUMBLER) VOLUME 23.5 cu. ft. 0.67cu. m.
DRYERS PER 20'/40' CONTAINER 10/20
DRYERS PER 45'/48' TRUCK 24/24
VOLTAGE AVAILABLE 208-460v 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 878 lbs. 453.6 kg
APPROX. WEIGHT (CRATED) 1,000 lbs. 544.3 kg
HEAT INPUT 350,000 btu/hr 88,200 kcal/hr
AIRFLOW 2,700 cfm 76.5 cmm
INLET PIPE CONNECTION* 1" N.P.T.
COMPRESSED AIR VOLUME 4 cfh 0.12 cmh
COMPRESSED AIR CONNECTION 1/8" F.P.T.
Shaded areas are stated in metric equivalents
* Size of piping varies with installation conditions.
