20
Each dryer should be connected to an independently protected branch circuit. The dryer must be connected
with copper wire only. DO NOT use aluminum wire, which could cause a fire hazard. The copper
conductor wire or cable must be of proper ampacity and insulation in accordance with electric codes for
making ALL service connections.
NOTE: The use of aluminum wire will VOID THE WARRANTY.
IMPORTANT: Wiring diagrams are affixed to the inside at the top front control door and to the rear
upper back guard or panel.
2. Electrical Service Specifications
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that is
affixed to the left side panel/wall area behind the control door. In the case of 208
VAC or 240 VAC, the supply voltage must match the electric service specifications
of the data label exactly.
IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC and 240 VAC ARE NOT THE SAME. Any damage done to dryer
components due to improper voltage connections will automatically VOID THE
WARRANTY.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
MLG-96D
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)*
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
MINIMUM
WIRE SIZE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz 60 Hz 50 Hz
208 3ш 3/4 * * 13.5 -- 2 5 --
240 3ш 3 * * 12.5 -- 2 5 --
380-400 3ш 3/4 * * -- 6.9 -- 15
416 3ш 3/4 * * -- 6.6 -- 15
460/480 3ш 3/4 * * 6.8 -- 15 --
* Contact factory for information not listed.
** AWG Stranded Wire Type ... size wire as per National Electrical Code or local codes.
