Water/ground source models, Applications, Performance – Fulton Invictus (IVS) Heat Pump Systems User Manual
Page 6: Thermal efficiency vs. source temperature, Hydronic cooling capacities: (ivs-095-w model), Hydronic heating efficiencies: (ivs-095-w model)

hot Water circuit Temperature
chilled Water
Inlet Temp.
95°f circuit
setpoint
104°f circuit
setpoint
113°f circuit
setpoint
122°f circuit
setpoint
140°f circuit
setpoint
(°f)
bTu/hr
Tons
bTu/hr
Tons
bTu/hr
Tons
bTu/hr
Tons
bTu/hr
Tons
32
55,900
4.66
53,900
4.49
50,500
4.21
46100
3.48
37600
3.13
41
57,400
4.78
56,000
4.67
53,500
4.46
49,800
4.15
43,100
3.59
50
58,200
4.85
57,300
4.78
55,800
4.65
53,300
4.44
48,000
4.00
59
58,400
4.87
58,000
4.83
57,100
4.76
55,600
4.63
52,000
4.33
68
58,400
4.87
58,100
4.84
57,500
4.79
56,600
4.72
54,800
4.57
77
59,400
4.87
58,100
4.84
57,500
4.79
56,700
4.73
56,000
4.67
WATER/GROUND SOURCE MODELS
APPLICATIONS:
The water/ground source heat pump
can be used for hydronic heating
and cooling applications. The IVS-
095-W model is for water source
applications and the IVS-095-WLB is
for ground source applications.
Hydronic Cooling Capacities:
(IVS-095-W Model)
Graphic: Ground source models are installed
indoors.
Hydronic Heating Efficiencies:
(IVS-095-W Model)
PERFORMANCE:
85
80
75
70
65
60
55
50
45
40
35
30
150
145
140
135
130
125
120
Source Temperature (°F)
Th
er
m
al
E
ffic
ie
nc
y,
P
er
ce
nt
95°F
104°F
113°F
122°F
131°F
149°F
Thermal Efficiency vs. Source Temperature
Heating
Setpoint:
To Well Field
To Heat Users
Return From Wells
Return From Users
To Well Field
To Cooling Users
Return From Wells
Return From Users
To Heat Users
Return From Users
To Cooling Users
Return From Users
