35
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
11 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
12 354030 1 Flat Gas Pipe Bracket
13 140026 1 Direct Spark Ignition (DSI) 3/4” 24 VAC Redundant
(natural gas) Gas Valve
140411 1 24 VAC Gas Valve Liquid Propane (L.P.) Conversion Kit
14 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
15 331291 1 Gas Valve Pipe Bracket
16 141208 1 3-Port Manifold
17** 140837 3 #8 Burner Orifice (natural gas) ONLY
140818 3 #31 Burner Orifice (liquid propane [L.P.] gas) ONLY
18 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
19 331288 1 Manifold Support ONLY
20 150309 6 #10-16 x 1/2” Hex Head TEK Crimptite Screw
21 141110 3 Burner Tube ONLY
22 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
23 331287 1 Burner Tube Support ONLY
24 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
25 150309 6 #10-16 x 1/2” Hex Head TEK Crimptite Screw
26 --------- 1 Sail Switch
(refer to Sail Switch Assembly on page 37)
27 331289 1 Burner Box Cover Plate ONLY
28 150309 1 #10-16 x 1/2” Hex Head TEK Crimptite Screw
29 331290 1 Ignitor/Flame-Probe Sight Hole Disc ONLY
30 880325 1 Ignitor/Flame-Probe Assembly Kit
(includes high voltage [HV] wire and connector)
305410 1 Direct Spark Ignition (DSI) Ignitor Gap Feeler Gauge ... Not Illustrated
31 880330 1 Direct Spark Ignition (DSI) Ignitor High Volage (HV)
Wire/Connector ONLY
32 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
33 151000 2 #6-32 Pal Nut
34 130401 1 330° Hi-Limit ONLY
35 150001 2 #6-32 x 1/2” Round Head Machine Screw
36 142924 1 1” to 3/4” Reducing Coupling
37 332256 1 Liquid Propane (L.P.) Burner Baffle
(for liquid propane [L.P.] models Only)
38 150309 5 #10-16 x 1/2” Hex Head TEK Crimptite Screw
--- 880876** 1 AD-115 Direct Spark Ignition (DSI) Liquid Propane (L.P.) Conversion Kit
39 142907 1 3/4” to 1/2” Reducing Bushing
* Orifices are not included and must be ordered separately.
** Consult factory for elevations over 2,000 feet.
Direct Spark Ignition (DSI) Burner Assembly
for Gas Models ONLY
