Tumbler (Basket)/Support Assemblies
Illus. No. Part No. Qty. Description
1 800707* 1 Tumbler (Basket) ONLY
800858* 1 Stainless Steel Tumbler (Basket) ONLY
800807 1 Tumbler (Basket) and Support Assembly Complete
(includes illus. nos. 1 through 12)
820054** 1 Tumbler (Basket) and Support Assembly Complete
(includes illus. nos. 1 through 12)
For Models with Rotation Sensor ONLY
800868 1 Stainless Steel Tumbler (Basket) and Support Assembly Complete
(includes illus. nos. 1 through 12)
820053** 1 Stainless Steel Tumbler (Basket) and Support Assembly Complete
(includes illus. nos. 1 through 12)
For Models with Rotation Sensor ONLY
2 150309 40 #10-16 x 1/2” Hex Head TEK Crimptite Screw
3 301300 4 Tumbler (Basket) Rib ONLY
301400 4 Stainless Steel Tumbler (Basket) Rib ONLY
4 150500 1 5/16-18 x 3/4” Socket Button Head Screw
5 100909 8 1/2-13 x 43” Tie Rod
6 301700 4 Tumbler (Basket) Reinforcing Plate ONLY
7 301701 *** Tumbler (Basket) Shim ONLY
8 800607 1 Tumbler (Basket) Support ONLY
880821 1 Tumbler (Basket) Support ONLY
(for models with rotation sensor Only)
9 152011 8 1/2-13 Hex Nut
10 153026 16 1/2” Lock Washer
11 153014 8 7/16” Flat Washer
12 116004 1 Felt Collar ONLY
-- 401010 1 #847 Adhesive for Felt Collar
13 821002 1 Rotation Magnet Holder Assembly
(for microprocessor models with optional rotation sensor)
* Felt collar is not included and must be ordered separately.
** Rotation Sensor Magnet Holder Assembly (Illus. no. 13) must be purchased separately.
*** As required.
