24
E. FRONT PANEL AND MAIN DOOR ASSEMBLIES
To Replace Main Door Switch
1. Discontinue electrical power to the dryer.
2. Open main door.
3. Remove the two (2) Phillips head screws holding the main door
switch bracket assembly in place.
4. Remove door switch bracket from front panel and disconnect wiring
from switch.
5. Disassemble door switch from bracket by removing two (2) Phillips
screws and nuts securing on switch to the housing.
6. Reverse this procedure for installing new door switch.
7. Reestablish electrical power to the dryer.
IMPORTANT: UNDER NO CIRCUMSTANCES should the
door switch be disabled.
To Replace Main Door Assembly
1. Remove screws holding top hinge block to front panel.
2. Remove door by lifting up off of bottom hinge.
3. Reverse this procedure for reinstalling new main door assembly.
