7
SECTION III
INSTALLATION REQUIREMENTS
Installation should be performed by competent technicians in accordance with local and state codes. In the
absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1-
LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical
Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91
(Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General
Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION
(for Electrical Connections).
A. ENCLOSURE, AIR SUPPLY, AND EXHAUST REQUIREMENTS
NOTE: The following information is very brief and general. For a detailed description, refer to the
Installation Manual supplied with the dryer.
Bulkheads and partitions around the dryer should be made of noncombustible materials. Allowances should
be made for the opening and closing of the control door and lint drawer. Also, allowances should be made in the
rear for ease of maintenance. (Refer to the appropriate Installation Manual for recommended distances and
minimum allowances required.)
When the dryer is operating, it draws in room air, heats it, passes this air through the basket (tumbler), and
exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the
make-up air is inadequate, drying time and drying efficiency will be adversely affected. Ignition problems and
sail switch “fluttering” problems on gas dryers may result, and you also could have premature motor failure from
overheating. The air supply must be given careful consideration to insure proper performance of each dryer.
IMPORTANT: Make-up air must be provided from a source free of dry cleaning fumes. Make-up
air that is contaminated by dry cleaning fumes will result in irreparable damage to the
motors and other dryer components.
Exhaust ductwork should be designed and installed by a competent technician. Improperly sized ductwork will
create excessive back pressure, which will result in slow drying, increased use of energy, and shutdown of the
burner by the airflow (sail) switch, burner hi-limit or lint chamber hi-heat protector thermostat. (Refer to the
appropriate Installation Manual for more details.)
CAUTION: IMPROPERLY SIZED OR INSTALLED EXHAUST DUCTWORK CAN
CREATE A POTENTIAL FIRE HAZARD.
