Chipset Features
Parallel Port Mode (ECP+EPP)
This field allows you to set the operation mode of the parallel port. The setting
Normal, allows normal-speed operation but in one direction only; EPP allows bidi-
rectional parallel port operation at maximum speed; ECP allows the parallel port to
operate in bidirectional mode and at a speed faster than the maximum data transfer
rate; ECP+EPP allows normal speed operation in a two-way mode.
ECP DMA Select (3)
This selection is available only if you select ECP or ECP+EPP in the
Parallel Port Mode. Select either DMA Channel 1, 3, or Disabled.
Onboard IR (Disabled)
When enabled, this field activates the onboard infrared feature and sets the second serial
UART to support the infrared module connector on the motherboard. If your system
already has a second serial port connected to the onboard COM2 connector, it will no
longer work if you enable the infrared feature. By default, this field is set to Disabled,
which leaves the second serial port UART to support the COM2 serial port connector.
IR Mode (IrDA SIR)
This motherboard supports IrDA compatible Serial Infrared (SIR) and Fast Infrared
(FIR) communication modes. The FIR mode has two options: FIR/HP and FIR/
IBM, for computers or peripherals using HP and IBM’s infrared transceivers, re-
spectively. When using either FIR option, FIR DMA Select must be configured to
reflect the DMA channel used by the port.
FIR DMA Select (1)
This allows you to configure the DMA channel used by the FIR port. Options are
DMA 1 (default) or DMA 3.
Onboard PCI IDE Enable (Both)
You can select to enable the Primary IDE channel, Secondary IDE channel, Both, or
Disable both channels (for systems with only SCSI drives).
IDE Ultra DMA Mode (Auto)
This sets the IDE UltraDMA to be active when using UltraDMA-capable IDE de-
vices. The BIOS will automatically adjust or disable this setting for slower IDE
devices so that Auto or high settings will not cause problems for older IDE devices.
Choose Disable if you do not want this feature for all devices.
IDE 0 Master/Slave PIO/DMA Mode, IDE 1 Master/Slave PIO/DMA Mode (Auto)
Each channel (0 and 1) has both a master and a slave making four IDE devices possible.
Because each IDE device may have a different Mode timing (0, 1, 2, 3, 4), it is necessary
for these to be independent. PIO and DMA timings can be independently set. The default
setting of Auto will allow autodetection to ensure optimal performance.
