PROLiNK PPL1201 Quick Installation Guide www.prolink2u.com
Version 1.00 Page 7 of 10 PPL1201
Section 6 : Hardware Connection - Internet
Follow the procedures describe below to connect the Ethernet Powerline Adaptor to your ADSL broadband
connection:
1. Power off your PC or Notebook.
2. Connect the provided Ethernet (RJ-45) cable to the PROLiNK® PPL1201 Powerline Ethernet Adapter’s
Ethernet port.
3. Connect the other end of the Ethernet (RJ-45) cable to an available Ethernet port of your ADSL broadband
Router.
4. Plug the PROLiNK® PPL1201 Powerline Ethernet Adapter into a wall socket next to the computer.
5. Turn on your computer.
6. Check and confirm that the Power, PROLiNK® PPL1201 Powerline Ethernet Adapter and Ethernet LEDs
on the PROLiNK® PPL1201 Powerline Ethernet Adapter are ON.
Remark:
Do not connect the Powerline Adaptor to an extension lead, power strip, extension cord, or surge protector as this
may degrade the network performance.
