PROLiNK PPL1201 Quick Installation Guide www.prolink2u.com
Version 1.00 Page 6 of 10 PPL1201
Section 5 : Hardware Connection - Computer
Following are the steps to properly connect the PROLiNK® PPL1201 Powerline Ethernet Adapter to your
computer:
1. Power off your PC or Notebook.
2. Connect the provided Ethernet (RJ-45) cable to the PROLiNK® PPL1201 Powerline Ethernet Adapter’s
Ethernet port.
3. Connect the other end of the Ethernet (RJ-45) cable to you computer’s LAN port.
4. Plug the PROLiNK® PPL1201 Powerline Ethernet Adapter into a wall socket next to the computer.
5. Turn on your computer.
6. Check and confirm that the Power and Ethernet LEDs on the PROLiNK® PPL1201 Powerline Ethernet
Adapter are ON.
