PROLiNK PLA-03 - Manual

PLA-03
Specification are subject to changes without prior notice due to engineering improvement. Wireless range and performance may vary with
environment. All brands and product names are trademarks or registered trademarks of their respective holders.
Lightning Arrestor
www.prolink2u.com
PLA-03 Lightning Arrestor
for 2.0 to 6.0 GHz
Electrical Specification
Mechanical Specification
Frequency (Ghz) 2.00 ~ 6.00
Insertion Loss (dB) 2.4 5.7
Gain (dBi) 0.4 dB 0.6 dB
Other Freq. Gain (dBi)
VSWR (Max)
1:1.7
Polarization Linear, vertical
RF Power (Watts) 15W
Impedance (Ω) 50 Ohms
Connector Termination N Plug (M)
Dimension (mm) Φ22 x 183 mm
Weight (gm) 70gm
0.9 dB Maximum
