OPERATION
Stored Position / Restraint UNLOCKED
Hook is in the STORED position. Inside light is flashing red
alerting forklift operator unsafe condition exists. Outside
light is flashing GREEN alerting truck driver it is safe to
back in. Inside light flashing RED
ENGAGE Button Pressed - Restraint ENGAGING
Trailer has backed into loading dock and is parked firmly
against dock bumpers. Hook rotates from stored position
to engage RIG. Outside light is flashing RED alerting truck
driver not to move. Inside light flashing GREEN.
If YELLOW caution light comes on proceed to FAULT,
otherwise proceed to Restraint ENGAGED.
RED
GREEN
RED
GREEN
