40 4111-0009 — Aug 2012
Jan 2013
PARTS
Motor and Blower Assembly
Item Quantity Part Number Description
9395-0359 PPAC,Blower Assy, Includes 1-4,7,8,10-14
1 1 Fan / Motor, 115VAC, AP Series Levelers
2 1 Shroud, Fan End
3 1 Shroud, Motor End
4 1 9391-0021 Filter Element
5 1
9391-0022 Tube, 2” (50.8mm) OD, 36” (914.4mm) Length 6’ and 8’ Levelers
9391-0041 Tube, 2” (50.8mm) OD, 46” (914.4mm) Length 10’ levelers
6 1
9392-0047 Pipe, PVC, 1-1/2” SCH40 X 24” (38.1 X 609.6mm)
9392-0068 Pipe, PVC, 1-1/2” SCH40 X 24” (38.1 X 609.6mm) With 90Deg Elbow
7 1 Cord Set, 115V, 3 Conductor, 6’ (1828.8mm) long
8 1 Cord Grip
9 4 9391-0023 Clamp, Tube
10 3 Screw, Cap, Socket Head, 1/4-2 X 1-1/2
11 5 2101-0143 Nut, Hex, Nylon Locking, 1/4-2
12 2 2101-0007 Screw, Cap, Hex, 1/4-2 X 1 LG
13 8 2101-0005 Washer, Flat 1/4”
14 1 Adaptor, Hose, 1-1/2 to 1-1/4
