37
4111-0009 — Aug 2012
Jan 2013
PARTS
Frame and Platform
Item Quantity Part Number Description
A 1 See Table A Lip, Welded Assembly
B 1 7823-____ 2 Platform, Welded Assembly
C 1
9202-0050 Pin, Lip Hinge 6’W
9202-0051 Pin, Lip Hinge 6.5W
9202-0052 Pin, Lip Hinge 7W
D 1
DKIT-9179 Toe Guard Assembly 6 Foot (Both Sides and Hardware)
DKIT-9180 Toe Guard Assembly 8 Foot (Both Sides and Hardware)
DKIT-9181 Toe Guard Assembly 10 Foot (Both Sides and Hardware)
E 2 2101-0039 Nylon Lock Nut, 5/16-18 UNC
F 4 2101-0163 Washer, 5/16 in., Flat
G 2 2101-0011 Cap Screw, 5/16-18 UNC x 1 in.
H 1 0015-____ 1 Frame,
I 3 9202-0002 Rear Hinge Pin
J 6 2101-0047 Cotter Pin, 1/4 x 2 in.
K 1
9224-0030 Maintenance Prop “39.50
9224-0031 Maintenance Prop “43.50
9224-0079 Maintenance Prop “39.50
L 1 9201-0009 Prop Pin & Clip
M 1 1751-0010 Decal, Model / Serial ID
N 2 2101-0046 Cotter Pin, 1/4 x 1-1/4 in.
1 Provide dock leveler serial number, platform size, and lip size when calling or faxing orders .
2 Provide length and width of inspection plate opening when calling or faxing orders .
* For left/right orientation of dock leveler, see inside back cover of this manual.
LIPS (Table A) from JAN 2012
6.0 FOOT 20K 25/30K 35K 40K 45K 50K
1 16 05 9 5-1500 05 9 5-1503 05 9 5-1506 05 9 5-150 9 05 9 5-1512 05 9 5-1515
1 18 05 9 5-1501 05 9 5-1504 05 9 5-1507 05 9 5-1510 05 9 5-1513 05 9 5-1516
1 20 05 9 5-1502 05 9 5-1505 05 9 5-1508 05 9 5-1511 05 9 5-1514 05 9 5-1517
6.5 FOOT
1 16 05 9 5-1518 05 9 5-1521 05 9 5-1524 05 9 5-1527 05 9 5-1530 05 9 5-1533
1 18 05 9 5-151 9 05 9 5-1522 05 9 5-1525 05 9 5-1528 05 9 5-1531 05 9 5-1534
1 20 05 9 5-1520 05 9 5-1523 05 9 5-1526 05 9 5-152 9 05 9 5-1532 05 9 5-1535
7.0 FOOT
1 16 05 9 5-1536 05 9 5-153 9 05 9 5-1542 05 9 5-1545 05 9 5-1548 05 9 5-1551
1 18 05 9 5-1537 05 9 5-1540 05 9 5-1543 05 9 5-1546 05 9 5-154 9 05 9 5-1552
1 20 05 9 5-1538 05 9 5-1541 05 9 5-1544 05 9 5-1547 05 9 5-1550 05 9 5-1553
