Op e ra tio n a n d C a re Ma n u a l • 4.
I N S TA L L AT I O N
Site Installation
O P T I O N S & A C C E S S O R I E S
39
"
(9
91
m
m
)
22
-1
/2
"
(5
72
m
m
)
2-
1/
2"
(6
4
m
m
)
CL
19
-1
/1
6"
(4
84
m
m
)
16-13/16" (411 mm)
17-3/16" (437 mm)
Electrical Connection
1-1/2” (38 mm)
from top
25
"
(6
35
m
m
)
10 0 F
15 0 200 250
300
35 0
OFF
39
-1
/4
"
(9
97
m
m
)
23
-3
/1
6"
(5
89
m
m
)
8-1/16" (205 mm)
CL
19
-3
/8
"
(4
93
m
m
)
13
-1
3/
16
"
(3
51
m
m
)
1-
1/
4"
(3
1
m
m
)
13-1/8" (333 mm)
16-1/8" (409mm)
17-1/8" (434 mm)
21
-1
/2
"
(5
47
m
m
)
25
-9
/1
6"
(6
50
m
m
)
Electrical
Connection
1-5/8” (40mm)
from top
Electrical
Cavity
Ca
vi
ty
Ca
vi
ty
500-E
500-E/Deluxe
Outside Dimensions
Cabinets can be stacked in multiples. There are four (4) 3/16" (5mm) rounded projections on the top and
bottom of each cabinet to permit stacking A center support stacking hardware kit (E-5091) must be used to
stack the deluxe cabinets.
500-E stacked height: 38-1/ 8" (968mm)
500-E/ Deluxe stacked height: 40-1/ 16" (1018mm)
500-E 500-E/Deluxe
Casters*, 3" (76mm) (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14227*
Casters*, 5" (127mm) (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4007*
Caster Stand Assembly with 5" (127mm) casters (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15377 . . . . . . . . . . . . . . . . . . .
Legs*, 6" (152mm) (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5205*
Leg Stand Assembly, with 6" (152mm) legs (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15378 . . . . . . . . . . . . . . . . . . .
Pan Slide Support (2 REQUIRED ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11002 . . . . . . . . . . . . . . . . . . .
Shelf, chrome plated wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .SH-2107 . . . . . . . . . . . . . . . . . . .
Stand Base Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-5089*
Stacking Hardware ( CENTER SUPPORT , BETWEEN UNITS ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-5091
Transport Door Latches ( FACTORY INSTALLATION ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .LT-2035 . . . . . . . . . . . . . . . . . . .
* s t a n d b a s e a s s e m b l y m u s t b e o r d e r e d w h e n o r d e r i n g c a s t e r s o r l e g s
