Op e ra tio n a n d C a re Ma n u a l • 16.
M A N U A L C O N T R O L • S E R V I C E
MODEL 500-E • Manual Control
1 . T O P 1 4 9 8 6
2 . T O P M O U N T I N G S C R E W S 9 S C - 2 4 2 5
3 . C O R D A N D P L U G S E T ( 1 2 5 V ) 1 C D - 3 0 2 9
C O R S E T : 2 3 0 V , I N T L ( T Y P E H O 7 R N - F ) 1 C D - 3 9 8 4
C O R D S E T : 2 0 8 - 2 4 0 V 1 C D - 3 8 5 8
4 . I N L E T ( 1 2 5 V ) 1 I T - 3 0 0 1
I N L E T ( 2 0 8 - 2 4 0 V ) 1 I T - 3 8 5 7
I N L E T ( 2 3 0 V ) 1 I T - 3 3 1 7 3
5 . C A S I N G , B O T T O M 1 1 3 6 0 / 1 3 5 5
6 . C A S I N G , B O T T O M , M O U N T I N G R I V E T S 1 0 R I - 2 1 0 0
7 . F A N , 1 2 5 V 1 F A - 3 4 8 5
F A N , 2 0 8 - 2 4 0 V , 2 3 0 V 1 F A - 3 3 4 2
F A N B L A D E 1 F A - 3 3 0 7 3
8 . I N S U L A T I O N :
2 5 ” x 5 4 ” ( 6 3 5 m m x 1 3 7 2 m m ) 1 I N - 2 2 3 6 4
2 5 ” x 5 4 ” ( 6 3 5 m m x 1 3 7 2 m m ) 1 2 5 V 1 I N - 2 3 8 1
9 . C A B L E C O N N E C T I O N H A R D W A R E ( n o t s h o w n )
1 0 . H E A T I N G C A B L E :
( 1 2 5 V ) — 5 1 ’ ( 1 5 5 4 5 m m ) l e n g t h 1 C B - 3 0 4 4
( 2 0 8 - 2 4 0 V , 2 3 0 V ) — 7 2 ’ (21946mm) length 1 C B - 3 0 4 5
1 1 . H I - L I M I T T H E R M O S T A T ( 2 3 0 V ) 1 T T - 3 8 5 9
1 2 . T H E R M O S T A T 1 T T - 3 0 5 7
T H E R M O S T A T K N O B ( F a h r e n h e i t ) 1 K N - 3 4 6 9
T H E R M O S T A T K N O B ( C e l s i u s ) 1 K N - 3 4 7 4
1 3 . H E A T I N D I C A T O R L I G H T ( 1 2 5 V ) 1 L I - 3 0 2 7
H E A T I N D I C A T O R ( 2 3 0 V a n d 2 0 8 - 2 4 0 V ) 1 L I - 3 9 5 1
1 4 . I N T E R I O R A M B I E N T T E M P . G A U G E 1 G U - 3 2 7 3
1 5 . C O N T R O L P A N E L O V E R L A Y 1 P E - 2 8 8 2
1 6 . D O O R A S S E M B L Y , R I G H T - H A N D 1 1 5 0 1 6
D O O R A S S E M B L Y , L E F T - H A N D 1 5 1 2 5
1 7 . H I N G E S E T ( 1 p a i r o f 2 h i n g e s ) 1 H G - 2 0 1 5
H I N G E M O U N T I N G S C R E W S ( n o t s h o w n ) 1 2 S C - 2 0 7 2
1 8 . D O O R H A N D L E 1 H D - 2 0 0 7
D O O R H A N D L E M O U N T I N G S C R E W S 3 S C - 2 0 7 3
D O O R S T R I K E R M O U N T I N G S C R E W S 3 S C - 2 0 7 1
1 9 . D O O R G A S K E T ( l e n g t h ) : 5 . 1 ’ ( 1 5 5 5 m m ) 1 G S - 2 3 9 8
2 0 . P A N S L I D E S 6 1 2 2 0
P A N S L I D E M O U N T I N G S C R E W S 1 2 S C - 2 2 6 8
2 1 . C A R R Y I N G H A N D L E , C H R O M E 4 H D - 2 5 3 2
M O U N T I N G S C R E W S 1 6 S C - 2 0 7 0
SERVICE VIEW on following page.
includes:
CB-3045 Cable Heating Element -- 85 feet 112 feet
CB-3044 Cable Heating Element 52 feet -- --
CR-3226 Ring Connector 4 4 6
IN-3488 Insulation Corner 1 foot 1 foot 1 foot
BU-3105 Shoulder Bushing 4 4 6
BU-3106 Cup Bushing 4 4 6
ST-2439 Stud 4 4 6
NU-2215 Hex Nut 8 8 12
SL-3063 Insulating Sleeve 4 4 6
TA-3540 Electrical Tape 1 roll 1 roll 1 roll
H E A T C A B L E R E P L A C E M E N T S E R V I C E K I T
#4873 #4878 #4879
125 V 208/240V 230V
3/18/04 QTY. ALTO-SHAAM
PART DESCRIPTION PER UNIT PART NO.
QTY. ALTO-SHAAM
PART DESCRIPTION PER UNIT PART NO.
