Hardware
5
Overview for Avaya IP600 Internet Protocol Communications Server
555-233-001 — Issue 5 — November 2000
1
Hardware
The major components of the Avaya IP600 include the following circuit packs: a
TN744 call classifier, TN2302AP IP media processor (IP gateway), a TN799C
C-LAN, and a TN795 processor. The processor circuit pack contains:
•
Windows NT 4.0 operating system with on-board Pentium processor chip
•
Secondary (Motorola) processor running application management firmware
•
NT to firmware interface
•
Tone clock functionality equivalent to a TN2182 circuit pack
•
AUDIX hardware/software with virtual AUDIX ports
•
Announcement hardware/software with virtual announcement ports
Rack-Mounted Cabinet
The Avaya IP600 rack-mounted cabinet weighs 40-50 pounds (180-225 kilograms)
fully loaded and is about 12 x 19 x 22 inches (30 x 48 x 55 centimeters — see
).
It includes 10 slots for circuit packs and a power supply and supports up to 400
ports (may require a second cabinet). The TN795 circuit pack must be in slot 2. The
cabinet is designed for rack mounting but can be floor mounted.
